Solar Panel Mono T1 LONGi

Product image 1
1 / 4

Solar Panel Mono T1 LONGi

DimensionsΒ

(𝐿2278 x 𝑀1134 x 𝑇35π‘šπ‘š)


Load Capacity
Maximum static load on the front (such as snow and wind)
5400Pa
Maximum static load on the back (such as wind)
2400Pa
Hail test
Diameter 25 mm, impact speed 23 m/s

Temperature Coefficient (STC test)

Temperature coefficient of short circuit current (Isc)
+0.050%/℃
Temperature coefficient of open circuit voltage (Voc)
-0.265%/℃
Temperature coefficient of peak power (Pmax)
-0.340%/℃

Warranty

  • 12Year on Material
  • 25 Year on power output

DimensionsΒ

(𝐿2278 x 𝑀1134 x 𝑇35π‘šπ‘š)


Load Capacity
Maximum static load on the front (such as snow and wind)
5400Pa
Maximum static load on the back (such as wind)
2400Pa
Hail test
Diameter 25 mm, impact speed 23 m/s

Temperature Coefficient (STC test)

Temperature coefficient of short circuit current (Isc)
+0.050%/℃
Temperature coefficient of open circuit voltage (Voc)
-0.265%/℃
Temperature coefficient of peak power (Pmax)
-0.340%/℃

Warranty

  • 12Year on Material
  • 25 Year on power output
$166.65
Solar Panel Mono T1 LONGiβ€”
$166.65

Description

DimensionsΒ

(𝐿2278 x 𝑀1134 x 𝑇35π‘šπ‘š)


Load Capacity
Maximum static load on the front (such as snow and wind)
5400Pa
Maximum static load on the back (such as wind)
2400Pa
Hail test
Diameter 25 mm, impact speed 23 m/s

Temperature Coefficient (STC test)

Temperature coefficient of short circuit current (Isc)
+0.050%/℃
Temperature coefficient of open circuit voltage (Voc)
-0.265%/℃
Temperature coefficient of peak power (Pmax)
-0.340%/℃

Warranty

  • 12Year on Material
  • 25 Year on power output
